What a Riser Block Kit Does
A riser block kit is designed to increase the vertical cutting capacity of your bandsaw, typically boosting it from 6 inches to 12 inches. The kit usually includes a cast iron or steel block, a longer blade guard, a guide post, and a new tensioning rod. Once installed between the upper and lower saw frame sections, it gives more clearance for thicker material. Riser kits are most commonly used on 14-inch models made by Delta, Jet, Rikon, Powermatic, and Grizzly.
Why Woodworkers Add Riser Blocks
Many woodworkers upgrade their saws with riser block kits to gain more cutting height without investing in a larger machine. This simple addition allows for resawing wider hardwood boards, preparing lumber for veneers, or shaping larger turning blanks.
Main Advantages:
• Expands cutting height by up to 6 additional inches
• Costs significantly less than purchasing a bigger saw
• Works with most 14-inch bandsaws
• Ideal for furniture makers, woodturners, and instrument builders
How a Riser Block Impacts Saw Operation
Adding a riser block changes both the geometry and performance of a saw. The extra height increases leverage on the upper frame, which can create minor vibration if the structure is light. Motor output also becomes more important, since smaller motors between ¾ and 1 horsepower may not deliver enough power for dense hardwood resawing.
Resawing Expectations and Setup
A riser block can help your saw cut taller boards, but your success depends on proper alignment and blade choice. Using a sharp, wide blade designed for resawing and keeping tension correctly adjusted will help produce smoother, straighter cuts with less drift.
Common 14-Inch Bandsaw Upgrade Kits Available on Guidekits.com
| Product Name | Compatible Models | Key Upgrade Type |
|---|---|---|
| Delta 14 Guide Upgrade Kit | Delta 14″, Jet 14″, and similar clones | Precision guide bearing kit |
| Jet 14 Riser Block Kit | Jet 14″ Bandsaws | Adds 6″ cutting height |
| Grizzly 14 Riser Block Kit | Grizzly 14″ Bandsaws | Expands resaw capacity |
What Affects Cut Quality After the Upgrade
While a riser block increases capacity, precision still depends on careful setup. Blade alignment, feed speed, and guide adjustments all influence how cleanly the saw performs on tall cuts. Regular inspection of these elements helps ensure smooth operation.
Key Points Before Installation
• Confirm your saw’s frame and bearings are aligned and solid
• Use a motor with at least ¾ horsepower for hardwood resawing
• Purchase longer blades, usually about 105 inches
• Recheck wheel alignment and balance after installing the block
• Adjust the blade guides and guard to match the added height
When Adding a Riser Block Is the Right Choice
A riser block is a valuable upgrade if you
• Resaw lumber wider than 6 inches on a regular basis
• Own a sturdy 14-inch bandsaw in good working condition
• Want more capability without upgrading to a bigger model
• Have experience with basic mechanical adjustments
When a Riser Block May Not Be Necessary
If your saw struggles with vibration or lacks sufficient power, a riser block might not be the right investment.
You may want to skip the upgrade if
• Your motor is under ¾ horsepower
• The frame flexes under heavy load
• You frequently resaw thick hardwoods up to 12 inches wide
• You plan to replace your saw with a 17-inch or 18-inch model soon
Resawing Tips for Better Efficiency
For the best performance, focus on setup and blade control.
Helpful Tips:
• Select a ½-inch to ¾-inch wide resaw blade with 3 TPI hook teeth
• Keep blade tension and tracking consistent
• Feed material slowly and steadily to prevent burning or drift
• Maintain clean dust collection for deeper cuts
Next Read: Delta 14-Inch Bandsaw Riser Block Upgrade Guide
If you’re planning to improve your saw’s cutting height and precision, check out “Delta 14-Inch Bandsaw Riser Block Upgrade Kit: Installation, Setup, and Performance Tips.” This article provides practical advice on installation steps, alignment checks, and ways to optimize your saw’s performance after adding a riser block for smoother, taller cuts.
Maintenance After Installing a Riser Block
A well-maintained saw delivers longer life and smoother cuts. Inspect blade tracking and guide bearings often, tighten riser bolts, and replace worn or dull blades as needed. Choose quality blades made for hardwood resawing to maintain accuracy over time.
A riser block kit is one of the most effective upgrades for expanding a 14-inch bandsaw’s capability. When properly installed and tuned, it allows you to resaw wider stock, make taller cuts, and handle more complex woodworking tasks at a reasonable cost.
If you resaw occasionally, a riser kit provides excellent value. However, for frequent heavy cutting, a larger machine with a more powerful motor will deliver faster and more consistent results.
Guidekits.com provides a range of riser block and guide upgrade kits for 14-inch bandsaws. Each kit includes precision-machined components and extended posts designed for increased height and smoother cutting performance. These upgrades help woodworkers achieve cleaner cuts, reduce vibration, and extend blade life.
